Simple and safe handling for your overhead line indicators
Accessories for overhead line short-circuit indicators
Here you will find a wide selection of high-quality accessories for professional installations on overhead lines. With Horstmann accessories, you can carry out your installations quickly, easily and professionally.
Our range includes:
Magnet for commissioning Smart Navigator 2.0
| Designation | Order no. |
|---|---|
| Magnet (test and reset) | 49-6001-002 |
Installation tool for Navigator and Smart Navigator 2.0
| Designation | Order no. |
|---|---|
| For installing and uninstalling the Navigator series | 49-6006-004 |
| For installing and uninstalling Smart Navigator 2.0 & LC | 49-6006-005 |
| To install and uninstall Smart Navigator 2.0 HV | 49-6006-006 |
Telescopic pole with universal toothed coupling
Suitable for the universal coupling of the installation tool
| Designation | Order no. |
|---|---|
| 65-0305-001 |
USB transmitter
For configuring the Smart Navigator 2.0 series via radio. Depending on the region, we offer the right variant for you
| Designation | Order no. |
|---|---|
| USB transmitter for Smart Navigator 2.0 | 28-5000-001 |
| USB transmitter for Smart Navigator 2.0 (915 MHz) | 28-5000-002 |
| USB transmitter for Smart Navigator 2.0 (923 MHz) | 28-5000-006 |
Operating rod with hook
For installing and uninstalling overhead line short-circuit indicators
The Navigator and Smart Navigator 2.0 can be securely fastened with the hook. The hook can be opened and closed using the handle.
| Nominal voltage [kV] | Dimensions [mm] a | b | c | Order no. |
|---|---|---|---|---|
| 1 – 24 | 1.200 | 500 | 310 | 65-0301-001 |
| 1 – 36 | 2.000 | 900 | 310 | 65-0301-002 |
| 1 – 36 | 3.000 | 900 | 310 | 65-0301-003 |
| 1 – 52 | 2.000 | 900 | 310 | 65-0301-004 |
Matching applications
Smart Navigator 2.0 |
Smart Navigator 2.0 HV
- Overhead line short-circuit indicator with fast fault detection
- Built-in mobile radio modem
- Remote reporting of measured values - highly accurate measured current values, load flow direction & conductor cable temperature
Navigator LM |
Navigator LM HV
- Overhead line short-circuit indicator with 360° LED display
- Load-dependent self-adjustment of the response current
- Navigator LM HV: permissible voltage ≤161 kV
iHost
- Software application for data transmission to the control room
- Browser-based user interface
- Cloud and server solution possible
